This is Doppia Mappa Grimaldello Bulgaro Professional Locksmith Tool for Double Bit Locks (DOPPIA MAPPA DECODER). We named this product series ProEdition – it can operate (open and decode) more than 35 different models of Double Bit Locks and we keep developing new models constantly.
Watch Videos
To make your life easier we have tried to show and explain every detail when working with our ProEdition Series Tools.
Doppia Mappa Grimaldello Bulgaro - PROEDITION SERIES
Features & Benefits
With these tools you can open no matter how the lock is oriented - you just need to make sure on which side (frontplane or backplane) the active pins are
EASY MANIPULATION OF THE LOCK
With ProEdition Series you can lift each lever (plate) of the Double Bit Locks to a specific height in order for the locking bolt to move.
EASY TO USE
EASY OPENING PROCEDURE
Similar sticks, similar procedures, different models. If you work with one model, you already know how to work with all models. Easy to use and learn
TRACTION IS THE KEY TO SUCCESS
Key to success – manipulation of the traction of the pins. Easy to do with the two hex keys – one for the bottom and one for the top of the stick
REPAIR NEEDED? NO PROBLEM
Easy to assemble and disassemble. Easy to repair any broken pin – just unscrew the top and/or bottom bolts and change the damaged pin.
Choose your
-
ProEdition Series
Atra Dierre Doppia Mappa Decoder 6 x 6 (+ Locktrap) NEW
Rated 0 out of 5280 € Add to cart -
ProEdition Series
CISA CAMBIO FACILE 3-5-3 + BIG MAP Cisa locks Pro Edition
Rated 0 out of 5310 € Add to cart -
ProEdition Series
Elbor/ Class PROEdition /Эльбор Кремень 3-3 / Kласс отмычка
Rated 0 out of 5200 € Add to cart -
ProEdition Series
MOTTURA NUCLEO COMPACT 6 pins ProEdition Series
Rated 5.00 out of 5200 € Add to cart -
ProEdition Series
Mottura Nucleo Compact 7 pin DOUBLE BIT LOCK PROEdition
Rated 0 out of 5200 € Add to cart
Choose your
Doppia Mappa Grimaldello Bulgaro
The most important thing is the preparation of the stick. On most models there are two bolts – one positioned on the top and another the bottom of the stick. There are two hex keys in the box – one for the top bolt of the stick and one for the bottom bolt. The first step of the preparation is to ensure the smooth traction of the pins. If you tighten the bolts too much, the pins will move very hard. Hence, this may cause very slow or even impossible opening. On the other hand - If you leave them too loose, the pins will move too easy. This can cause the following - during the opening procedure, their movement will be gone. In other words , this will make the opening impossible. The pins must have the correct traction – not too tight nor too loose!
- model stick (Atra, Mottura, Cisa, Securemme ...etc)
- Universal Handle suitable for every model
- Small tension Handle
- 2 hex keys
- bolt for external pin adjustment
- graphite stick for greasing the tool
- small box with additional pins (spare parts)
- Durable Transport box
DOUBLE BIT LOCKS?
The Double Bit locks are built and operate much differently than the conventional and more popular pin locks. Their biggest disadvantage is that they do not allow for as many master-key combinations as pin tumbler locks. In a basic, fixed, lever lock design, the entire lock is enclosed in a case – The simple lever lock has three or more lever wafers or plates that pivot on a post and are pushed into the ‘locking’ position by springs, which are bound against the case and attached to the tail end of each lever plate. When the original key is inserted into the lock and turned, it raises each plate (wafer) to the point where the fence of the lock’s bolt can clear the obstruction or face of each wafer, which also blocks each tumbler’s gate. When all the levers are in this position, the fence can be thrown through each tumbler’s gate, which pushes the bolt into the retracted position.
